B+M Key M.2 to 2.5 Gigabit Ethernet Adapter (2500Mbps)
B+M Key M.2 to 2.5 Gigabit Ethernet Adapter (2500Mbps)
Regular price
$17.40 USD
Regular price
Sale price
$17.40 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
The B+M Key M.2 to 2.5 Gigabit Ethernet Adapter uses a high-performance Intel I226-V Ethernet controller. The Intel I226-V controller has a Base-T copper network interface that provides a compact single-port integrated Multi-Gigabit (2.5G) – MDI (copper) standard IEEE802.3 Ethernet interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, and 10BASE-TE connections.
| Applicable Network | 2.5G server network card |
| Main Controller | Intel(R) I226-V |
| Bus Type | M.2 B+M KEY |
| Media Interface | 1 x RJ45 copper cable |
| Transmission Rate | 2.5G/1000/100Mbps |
| Network Topology | 2500BASE-T, 1000BASE-T, 100BASE-TX, 10BASE-TE IEEE 802.3bz, IEEE 802.3, IEEE 802.3x, IEEE 1588, IEEE 802.3az - Energy Efficient Ethernet (EEE) |
| Management Function | IPMI transmission via SMBus or NC-SI, iSCSI boot, WoL, PXE remote boot, VLAN filtering |
| Operating System | Microsoft Windows 10 32/64-bit |
| Operating Temperature | 0 ~ 55 ℃ (32 ~ 131℉) |
| Storage Temperature | -40 ~ 70℃ (-40 ~ 158℉) |
| Certification | FCC, CE, RoHS |
| Storage Humidity | 90% non-condensing relative humidity at 35℃ |
